Applied to a wide range of fields of CNC coiling machine control system, automatic winding machine has the automatic vent line function, in various types of coil winding process can see the figure of it, the system integrates the function of we commonly used in the processing of winding, the control circuit for the control and signal equipment input are integrated together, the system can also with the model of the application of the differences in configuration.
Wire wheel is the structure of the winding machine directly in contact with the enameled wire mechanism, there are certain differences in the structure of wire wheel of different types of wire, our common winding process has flat wire, single strand round wire, multi-strand round wire, etc., the following we talk about the three types of winding process configuration of wire wheel application.
The groove of the flat wire conductor wheel is mainly rectangular or rectangular, and the width and thickness of the guide wheel are larger than that of the conventional wire wheel. Because the winding section of the flat wire is mainly rectangular, the spacing of the wheel groove is adjusted according to different wire diameters; V-shaped guide wheel is generally used when single strand round wire is wound, and the wire can be effectively guided in the V-slot. The standard configuration of many automatic winding machine wire wheel is generally V-shaped guide wheel. The winding of multi-strand round wire requires a enameled wire, so its configuration requires a U-shaped guide wheel.
Different automatic winding machine has different winding process, wire wheel is the same, different types of wire wheel material is also a certain difference, metal, nylon, copper and aluminum alloy materials, these are commonly used wire wheel materials, some special winding process configuration wire wheel is also special.
