Fully Automatic Single-Axis, Single-Station PFC Magnetic Ring Winding Machine

1. Technical Specifications



Equipment Parameters / Requirements
Equipment dimensions	L 1200mm, W 1600mm, H 1700mm
Control system	Servo module bus control, with Ethernet port for MES system connection
Interface	Reserved interface for connecting with rear automatic production line
Working process	Automatic feeding – Magnetic core winding – Discharging
Wire range	Width 1mm–4mm, Thickness 0.3mm–2mm (proper deviation according to forming circle size)
Pneumatic components	AIRTAC or equivalent level
Safety	Comply with safety production requirements
Production cycle	500–600 PCS/H (varies with forming circle wire length)



2. Overall Equipment Layout



1.Centrifugal feeder feeding → Conveyor line positioning → Transverse module loading & unloading → Forming module forming → Transverse discharge



2.Components: Touch screen control, feeding conveyor line, forming mold, centrifugal feeder, winding equipment, transverse handling



3. Equipment Module – Description



Equipment Parameters

Working voltage: 220V/50Hz

Power: 2200W

Dimensions: L1200 × W1600 × H1700mm



Main Components

Manipulator: Top domestic brand

Power supply: Taiwan brand or top domestic brand

Pneumatic components: AIRTAC or equivalent level





Factory:



video：
