Flat Wire Coil Winding Machine
Model:GWSX-9
Spindle number：1
Wire diameter：0.1-1.5mm
Swing diameter：0-280mm
Wire Arrangement Spacing:0-180mm
Description
|
Spindle number |
1 |
|
Spindle speed |
0-1200rpm |
|
Wire diameter |
0.1-1.5mm |
|
Nominal application diameter of tensioner |
0.10-0.50mm |
|
Swing diameter |
0-280mm |
|
Wire Arrangement Spacing |
0-180mm |
|
Wire Arrangement Speed |
0-22mm/sec |
|
Spindle motor |
1.5kW three-phase AC motor +1.5KW frequency converter |
|
Wire Arrangement Motor |
Two-phase hybrid stepper motor, static torque 2N.M |
|
Power Supply |
Single-phase 220V±10% 50HZ |
|
Machine Power |
1.7KW |
|
Machine size |
Length: 900mm width: 500mm height: 665mm |
|
Machine weight |
110Kg |
|
Multi-line and round |
Changing part of the configuration enables multi-wire and winding |
The flat wire coil winding machine with CNC technology is the perfect solution for efficient and precise coil winding. This innovative machine is designed to meet all of your coil winding needs with its plunge toroid winding feature. With this machine, you can produce high-quality coils that meet the most stringent quality standards.
The CNC technology used in this machine ensures accuracy and repeatability in every winding cycle. This machine offers unparalleled flexibility and precision, making it ideal for a wide range of applications, from transformers to motors and generators.
The plunge toroid winding feature also allows for the production of coils with complex geometries and angles, making it ideal for custom coil winding projects. With an intuitive user interface, this machine is easy to use, and can be customized to meet your specific needs.
Overall, the flat wire coil winding machine with CNC technology and plunge toroid winding is a reliable and efficient solution for your coil winding needs. It is designed to streamline the manufacturing process and produce high-quality coils with precision and speed. Invest in this machine today, and experience the benefits of efficient and reliable coil winding technology.
