Automatic Transformer Toroid Core Coil Winding Machine

SPECIFICATION:

Suitable winding diameter range	0.8-2.5m (single enameled copper wire, when multiple strands are wound together, the combined strength does not exceed the maximum value)
Finally completed outer diameter	80-250mm or 150-400mm (choose 1 from 2 fixtures)
Minimum completed inner diameter	40mm (with 8mm wire storage ring installed)
Maximum finished height	150mm
Width of magazine	8-20mm (optional), maximum customizable 40mm
Magazine circumference	1070mm
Maximum winding speed	230 rpm
Presetable programs	50*20 groups (1000 running programs)
Overall machine weight	138kg

FEATURES：

1.Toroid Transformer Winding Machine are advanced,strongly built workhorses capable of winding light as well as heavy wire without insulation damage.

2.The open gap gear rack and hinged gap magazine of Toroid Transformer Winding Machine facilitate core change ,maximzing output.

3.Easily exchangeable magazines secure maximum flexbility.

4.Extremely powerful,maintenance free AC motors for main drive and core rotation.

5.High technical winding shuttle for winding by highest efficiency.

6.Toroid Transformer Winding Machine can accurately count length of loading by limited-switch.

7.Toroid Transformer Winding Machine can accurately count turns of winding and taping by photo-electricity sensor.

ADVANTAGES:

1.Stable machine performance

2.Communicate parameters in a timely and thoughtful manner

3.Wide range of application, Large range of Speed adjustment, wide range of the wire diameter, Multi-style of core, Brake tension adjustable, Good settlement for large outer diameter, small inner diameter, heavy wire coils.

4.High production efficiency, increase winding efficiency by adjustment of suitable brake tension,

5.Each wiring part guarantee no wire damage.

6.Parts highly optimized and universal for general use, Easy maintenance

7.Complete specifications and data.

APPLICATION:

Toroid Winding Machine is the best suited to toroidal inductor, toroidal transformers,toroidal current transformers,toroidal coil, toroid choke coil, power inductors,UPS inductor,converter inductor and heavy toroidal core etc.
