1 Spindle Dual Arm Winding Machine Through Tube & Taping Multifunctional

Specification：Main technical parameters：(unit：mm)

	Item	Parameter
1	Spindle	1
2	Maximum Speed	8000 RPM
3	Spindle Servo Motor Power	400W
4	Spindle Winding Rotation Direction	CW&CCW
5	Applicable Wire Diameter	0.2-0.8mm
6	Bobbin Size	5-70mm
7	Power Supply	220V
8	Spindle Movement Range	X:200 Y:250 Z:150
9	Dimensions	1400(L)*1400(W)*1700(H)
10	Power	4000W
11	Machine Weight	480KG
12	Taping width	2mm-15mm/ barricade2mm-6mm
13	Air Compression	0.64Mpa

FEATURES:



1. The key components of this series of machine are all imported from Japan with high reliability and durability to greatly prolong the lifetime of the machines.



2. Novel design, simple structure, strong rigidity, simple operation and easy maintenance.



3. Programmed by computer or touch screen, free to choose and easy to understand in Chinese or English.



4. Unique design on the quick coupling fixture to save the time of changing different models.



5. Can achieve a variety of functions such as wrapping terminal, flying wire, wire through the tube, wrapping tape, margin tape, fix tape, floating tape etc.



6. Capable of various types of enameled wires, insulated wires, litz wires (with additional mechanisms), multiple wires, silk wrapped wires, and film wrapped wires etc winding process.



7. Use precision tension unit with back tension control to make the wire more tidy when aligning.



8. With optional automatic loading and unloading function to greatly save the time of winding.



9. Automatically damp, pull apart and remove the wasted wire.



10. With password saving function to avoid the modification of program by non - related personnel.



11. Can have tube detection function, automatic positioning function to prevent the wire not passing through the tube.
