Industrial Equipment CNC Turning Winding Shaft for CNC Machine Crank Shaft Shaft Sleeve

We always aim to become an excellent supplier of Parallel Winding Machine, CNC Coil Winder, Toroid Digital Transformer Coil Winding Machine, follow the business philosophy of 'integrity, cooperation, and win-win', and actively provide customers with high-quality products services. Our enterprise spirit embodies the characteristics of keeping pace with the times and is an advanced group consciousness recognized by the masses of workers. We welcome each individual to create value for the company through their own ideas, backgrounds and perspectives. The purpose of our company is to "create value and share results". We take technology as the driving force, customer as the leading, and constantly launch high-tech and good market prospects.

NAME:ACGW23-2CNC two spindle Winding Machine

Specifications

Spindle number	2
Wire size range	0.1-1.2mm
Loop diameter	80mm
Max wire distance	9.99mm
Winder width	100mm
Max. speed	4000RPM
Spindle motor	Three Phase motor+AC Drivers
Winder motor	stepping motor
Max. winder diameter	80mm
Input power	220V 50HZ/60HZ
Machine size	460×660×600mm
Package size	540×730×580mm
Net weight	70kg
Gross weight	88kg

Features:

Two spindle synchronous designs conform to customers winding the thicker diameter ,winding demanding developed

Winder .

Professional winding various long type coil, two side spindle synchronous rotation, stable and reliable.

CNC two spindle Winding Machine design of 32 bit controller chip, It’ll be faster and higher reliability.

In Chinese and English display,easy to operation,winding data retention after power failure, not to discarded products.

All the parts for two spindle Winding Machines are imported prats,such as:Japan Bearing (NSK、NTN),Japan BANDO belt ，Japan GATES belt ，Taiwan Ball screw (TBI)，Taiwan AC Drive and so on.

Advantage：

CNC two spindle Winding Machine use high quality bearing steel, reinforced machine body, to ensure product stability.

Pull lever tail stock design,operation more faster and convenient.

Adjustable wire shelf, to prevent loose wire. (Optional)

PRODUCT:

APPLICATION:

CNC two spindle Winding Machine for application of insulation tape to wound coils. it is best suited to toroidal inductor, toroidal transformer, toroidal current transformer, toroidal coil, toroid choke coil, power inductors, power magnetics, UPS inductor, converter inductors, heavy toroidal core,etc.

The coil is placed by an operator on a rotating spindle, and the machine automatically applies the required number of turns of insulation tape, secures the end of the tape with a wiping action, and ejects the coil from the machine.

It's an accurately and reliability digital automatic toroid-taping machine. it is used for wraping the insulation tape on the toroidal core and windings. Automatic Toroid Transformer Coil Taping Machine is designed to operate with a wide variety of insulation tapes, including Kapton, Polyester, PEN, PVC, PPS, and most other woven and non-woven types.

PRACTICAL APPLICATION :

TRAINNING CUSTOMER TO OPERATE WINDING MACHNE :
1.All service engineers with 10 years experience are gotten special technology training, who can deal with various breakdown problem.
2.Guide the user to use accurately and how to maintain the product.
Provide free consultation about production process technology of electronic products.
3.In order to guarantee the machine used normally, we'd have training on how to operate, use and maintain our product by English manual, video, guiding on line.

PACKAGING:

Packaging Material: Carton/Wooden case with foam inside.
1.General package(Paper carton or plastic bag): For small euipped parts for Toroidal Transformer Winding Machine , Package it with form and pack paper to guarantee unbroken during the transport.
2.Wooden case package: For larger scale Toroidal Winding machine ,we have special skilled carpenter, who would make the proper wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock.

Below is the name of all listed accessories for the machine and construction diagram.

(Note:Different machines have different equiped parts)

FREQUENCY CONVERTER	IRON COUNTER
BIG GEAR RING	HAND RING GEAR
INTERFACE GEAR	MAINSHAFT GEAR
IMPORTED BEARING	WIRE PULLEY
WIRE GUIDER BASE	GREEN SWITCH
POTENTIOMETER	LEFT RIGHT SWITCH
TRANSDUCER PNP	COUNTER WIRE
CASE CIRCUIT BOARD	THE BOARD OF THE CASE BACK
CONTROLLER	TAPE CUTTER
BRAKE UNIT	WIRE GUIDE WHEEL
DISPLAY AND CONTROLLER FOR MAGAZINE ROTATION	WIRE GUIDE HOLDER
FOOT PADALS	PCB BOARD FOR FOOT PADALS
LEATHER BELT	LEATHER PAD
FAN	SPRING FOR TAPE

FACTORY:

We-GREWIN INDUSTRIAL GROUP is expert in winding machines lines for 28Years. Our Grewin have ISO9001:2015,CE approvals,Machines'Patents,"high-tech enterprises"by the government.

Our focus on should be to consolidate and enhance the quality and repair of present products, in the meantime constantly establish new products to meet unique customers' requires for Industrial Equipment CNC Turning Winding Shaft for CNC Machine Crank Shaft Shaft Sleeve. We insist on doing the right one and keep improving the level, correct the wrong one and prevent it from happening again. We will continue to forge ahead, continue to innovate, and continue to meet consumers' requirements for product quality and safety.
