NAME：GWTM-0418 Gear Head Automatic Taping Machine

SPECIFICATION

Tape width	15(20,25,30)	Max.winding speed	120rpm
Max.final coil.O.D	φ130—650	Tape spacing	Proportional linkage
Min.final coil.I.D	φ60	Supply voltage	AC 220V（50Hz）
Max.finalcoil height	150	Mechanical dimensions	900×600×1800
Controller storage capacity Programs	29 set	Weight	240kg

FEATURES：

Gear Head Automatic Taping Machine will place insulating tapes on cores and windings in closely controlled fashion.

Automatic Taping Machines are fast and will work with polyester,polyimide and Aramide tapes as well as copper shielding tapes in widths from 6 to 16mm or as specified.

Tape is loaded onto the magazine and cut automatically，and the winding speed increased in order to finish the job in minimum time.

The magazine of Automatic gear head taping machine may be exchanged in minutes to accommodate different tape widths.

ADVANTAGES:

High accuracy: stepper motor guarantees high accuracy

The cut surface is flat: the hot knife can heat seal the cut surface of the color ribbon and the light and thin textile belt, and the sealing is smooth and free of burrs.

The blade is made of imported high-quality steel and has a long service life.

Automatic operation: just set the length and number of cuts you need, and the rest of the work is done automatically.

Automatic pause: Once the material is used up, Gear Head Automatic Taping Machine will automatically stop working. Bouncer automatic alarm

Memory function: automatically store the cut length, cut quantity and cut speed before shutdown

PRODUCT:

APPLICATION:

Gear Head Automatic Taping Machine for application of insulation tape to wound coils. it is best suited to toroidal inductor, toroidal transformer, toroidal current transformer, toroidal coil, toroid choke coil, power inductors, power magnetics, UPS inductor, converter inductors, heavy toroidal core,etc.

The coil is placed by an operator on a rotating spindle, and the machine automatically applies the required number of turns of insulation tape, secures the end of the tape with a wiping action, and ejects the coil from the machine.

It's an accurately and reliability digital automatic toroid-taping machine. it is used for wraping the insulation tape on the toroidal core and windings. Automatic Toroid Transformer Coil Taping Machine is designed to operate with a wide variety of insulation tapes, including Kapton, Polyester, PEN, PVC, PPS, and most other woven and non-woven types.
