NAME：GWM-0319B Toroid Transformer Winding Machine

SPECIFICATION：

Wire diameter	0.50—1.30	Max.winding speed	200rpm
Max.final coil.O.D	φ60—200	Wire spacing	Proportional linkage
Min.final coil.I.D	φ25	Supply voltage	AC 220V（50Hz）
Max.finalcoil height	80	Mechanical dimensions	550×500×750
Controller storage capacity Programs	29 set	Weight	94kg

FEATURES：

GWM-0319B Toroid Transformer Winding Machine are advanced,strongly built workhorses capable of winding light as well as heavy wire without insulation damage.

The open gap gear rack and hinged gap magazine of Toroid Transformer Winding Machine facilitate core change ,maximzing output.

Easily exchangeable magazines secure maximum flexbility.

Extremely powerful,maintenance free AC motors for main drive and core rotation.

High technical winding shuttle for winding by highest efficiency.

Toroid Transformer Winding Machine can accurately count length of loading by limited-switch.

Toroid Transformer Winding Machine can accurately count turns of winding and taping by photo-electricity sensor.



ADVANTAGES:

Stable machine performance

Communicate parameters in a timely and thoughtful manner

Wide range of application, Large range of Speed adjustment, wide range of the wire diameter, Multi-style of core, Brake tension adjustable, Good settlement for large outer diameter, small inner diameter, heavy wire coils.

High production efficiency, increase winding efficiency by adjustment of suitable brake tension,

Each wiring part guarantee no wire damage.

Parts highly optimized and universal for general use, Easy maintenance

Complete specifications and data

Easy maintenance of equipment

PRODUCT:

APPLICATION:

Toroid Winding Machine is the best suited to toroidal inductor, toroidal transformers,toroidal current transformers,toroidal coil, toroid choke coil, power inductors,UPS inductor,converter inductor and heavy toroidal core etc.

PRACTICAL APPLICATION :

TRAINNING CUSTOMER TO OPERATE WINDING MACHNE :
1.All service engineers with 10 years experience are gotten special technology training, who can deal with various breakdown problem.
2.Guide the user to use accurately and how to maintain the product.
Provide free consultation about production process technology of electronic products.
3.In order to guarantee the machine used normally, we'd have training on how to operate, use and maintain our product by English manual, video, guiding on line.

PACKAGING:

Packaging Material: Carton/Wooden case with foam inside.
1.General package(Paper carton or plastic bag): For small euipped parts for Toroidal Transformer Winding Machine , Package it with form and pack paper to guarantee unbroken during the transport.
2.Wooden case package: For larger scale Toroidal Winding machine ,we have special skilled carpenter, who would make the proper wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock.

Below is the name of all listed accessories for the machine and construction diagram.

(Note:Different machines have different equiped parts)

FREQUENCY CONVERTER	IRON COUNTER
BIG GEAR RING	HAND RING GEAR
INTERFACE GEAR	MAINSHAFT GEAR
IMPORTED BEARING	WIRE PULLEY
WIRE GUIDER BASE	GREEN SWITCH
POTENTIOMETER	LEFT RIGHT SWITCH
TRANSDUCER PNP	COUNTER WIRE
CASE CIRCUIT BOARD	THE BOARD OF THE CASE BACK
CONTROLLER	TAPE CUTTER
BRAKE UNIT	WIRE GUIDE WHEEL
DISPLAY AND CONTROLLER FOR MAGAZINE ROTATION	WIRE GUIDE HOLDER
FOOT PADALS	PCB BOARD FOR FOOT PADALS
LEATHER BELT	LEATHER PAD
FAN	SPRING FOR TAPE
