Fully Automatic Soldering Machine

1. Product fixture: The distance can be adjusted according to different product structures, and the fixture can be replaced in Wuxi.
2. Adhesive soldering flux: adjustable to any angle and depth, with soldering assistance flowing into the soldering flux slot using a drip method.
3. Soldering: Adjustable angle ± 45 ° corner soldering, depth, time, etc. Equipped with (depth detection, preheating soldering
Auxiliary functions such as lateral movement and rinsing.
4. Cooling: Install a constant current fan with adjustable time and coordinates.
5. Feeding: The product is manually placed on the platform or feeding assembly line, and the machine automatically picks up the product.
6. Cutting: The machine automatically places the products in the turnover box, and the row spacing and number of trays can be set.
7. Applicable products: Soldering of high and low frequency transformers, magnetic ring inductors, coils and other electronic products.

SPECIFICATION:

◆Industrial man-machine interface, 7-inch TFT touch LCD.

◆Specialized interface design, convenient operation.

◆Embedded modular design, powerful, customers can program according to their own needs.

◆ Memory retention No battery design, EEPROM storage, the shortest maintained for ten years.

◆Up to 256 sets of product data, up to 120 steps per group.

◆Can be used for different occasions, change the installed settings, the use of a wider range.

◆The program provides free upgrades.

APPLICATION:

Fully Automatically Soldering Machine for transformer, high frequency transformer,low frequency transformer,coils ,inductors
