Automatic Winding Machine for Transformer

NAME：GW-9620 Automatic Winding Machine For Transformer

SPECIFICATION:

FEATURES:

The Automatic Winding Machine For Transformer can control and process the winding process while winding at high speed. It can synchronously arrange the winding with 3 axes and complete the special process of winding with high requirements.

PLC control, easy to operate and learn;

High efficiency, suitable for professional production enterprises for mass production;

The width of the line is adjustable, and the number of turns is accurate.

High technical strong winding shuttle for widing the so thick wire highest efficiency.

Separate speed controls for loading and winding.

Automatic Winding Machine For Transformer can accurately count length of loading by limited-switch.

Automatic Winding Machine For Transformer can accurately count turns of winding by photo-electricity sensor.

Programmable winding direction ,winding returns range(Turns or Angle)and segment winding angle.

Memory capacity accommodates 29 sets programes with off-power memory retention.

ADVANTAGES:

The Automatic Winding Machine point can be set in sections. Width, line distance and speed, etc., in order to achieve the purpose of multi-section and multi-speed.

Can set 999 step sequence, and can store the set value for more than one year.

The wire frame is controlled by magnetic damping tension regulator and cylinder to achieve the purpose of precise tension adjustment.

The tail seat adopts cylinder type control, the operation is more convenient and quick.

The Automatic Winding Machine can accurately adjust the automatic winding machine winding speed, tie number, time, debugging is also convenient.

The line is compact and neat, the line diameter deformation is not affected.

PRODUCT:

APPLICATION:

Automatic Coil winding Machines are used for winding the small EI transformers, signal transformers, inductors, filter choke coil, relays, current contactors, valve coils, solenoid coils, telecom bobbin transformers. It can complete the coils without any one operator in fully automatically.

PRACTICAL APPLICATION :

TRAINNING CUSTOMER TO OPERATE WINDING MACHNE :
1.All service engineers with 10 years experience are gotten special technology training, who can deal with various breakdown problem.
2.Guide the user to use accurately and how to maintain the product.
Provide free consultation about production process technology of electronic products.
3.In order to guarantee the machine used normally, we'd have training on how to operate, use and maintain our product by English manual, video, guiding on line.

PACKAGING:

Packaging Material: Carton/Wooden case with foam inside.
1.General package(Paper carton or plastic bag): For small euipped parts for Toroidal Transformer Winding Machine , Package it with form and pack paper to guarantee unbroken during the transport.
2.Wooden case package: For larger scale Toroidal Winding machine ,we have special skilled carpenter, who would make the proper wooden case with exact thickness,density,length. The up arrow ↑marked on the outer wooden case. Buffer material would be put in the wooden case to prevent crack and shock.

OPTIONAL ACCESSORIES

FACTORY:

We-GREWIN INDUSTRIAL GROUP is expert in winding machines lines for 28Years. Our Grewin have ISO9001:2015,CE approvals,Machines'Patents,"high-tech enterprises"by the government.
