Full Automatic Small Toroidal Transformer Coil Winding Machine

SPECIFICATION:

Machine head	GWT-800A-S4	GWT-800A-S5	GWT-800A-S6
Wire diameter	0.06-0.18mm	0.1-0.28mm	0.1-0.28mm
Minimum finish inner diameter	6mm	8mm	10mm
Core height	4-15mm	5-15mm	5-20mm
Core outer diameter	10-25mm	20-40mm	20-40mm
Magazine inner diameter	98mm	120mm	135mm
Magazine height (mm)	2.8, 3, 3.2, 3.5, 4, 4.2	3.5, 4, 4.5, 5, 5.5, 6, 7	4.5, 5, 5.5, 6, 6.5, 7
Machine size	110*60*132cm

MACHINE INTRODUCTION：

The GWT-800A is an up-to-date high speed automatic winding machine to mini type coils production on large scale. This model machine can assist you to finish some production which request of high output and high quality with low cost. In order to solve down mini type core with fine wire and difficulty to operation, GWT-800A use new design for pay-off core automatic, pay-off wire automatic. During production, it doesn't use manual operation. It decrease labor's strength.Meanwhile it guarantee the

quality of coils. The user friendly PLC software guides the operator thru the programming with clear text commands. It is easy to operate the machine.It keep the feature of easy operation about GWT-800A machine. This control system use Chinese and English version.the guide roller use stepper motor driver, easy to adjust wire pitch and precision control.



MACHINE FEATURES:

1.Independent loading wire speed and length control

2.Independent traverse speed and turn control.

3.Display language with Chinese and English, and touch panel operation.

4.Display current state and easy to check data.

5.Programming control stepper motor to drive core and run to any direction.

6.Controller memory some winding programs, each program edit different winding step sequence to fit for different request.

7.Set up the high speed fiber optic sensor. It display even number. Convenience to adjust and precise steady.

8.Control variable pitch, from sparse traverse to tiny traverse to get the result through programming.

9.Use servo motor, loading wire precise highly and speed steady. Loading and traverse speed switch steady.



PACKAGING:





FACTORY:







VIDEO：
