Products

Model：GWD-S06
Spindle：6
Spindle spacing: 50.7mm
Spindle servo motor power:1500KW -- 2000KW
Wire diameter:0.02mm -- 0.8mm

Model：GWP-02N
Spindle：1
Spindle speed：2000rpm
Winding width：X:180 Y:200
Winding diameter：320mm（Max）
Wire diameter：0.03-1.5mm (Upgradable)

Wire range:0.4-1.6mm
Magazine diameter:175mm
Finished core OD:16-70mm
Finished core ID:8mm
Finished core HIEGHT:25mm
Max.winding speed RPM:800rpm/min

Modl：GWT-670
Max. Wire Diameter: 1.2 mm
Min. Wire Diameter: 0.06mm
Max. Finished O.D.: 25.4mm
Min. Finished O.D.: 2.54mm
Min. Finished I.D.: 0.8mm ...

Equipment model：GWA-DM009
Applicable core Out diameter： 20-57mm
Inner diameter：greater than 8mm
Height ：5-30mm(different core size with different fixture)
Wire...

Equipment model：GWA-DM009
Applicable core：
Out diameter： 20-57mm
Inner diameter：greater than 8mm
Height ：5-30mm(different core size with different fixture)
Wire...

Equipment model GWA-70HD
Adapt to the magnetic ring (outer diameter): 14mm-45mm
Adapt to wire diameter: 0.5mm-2.0mm

Model:GWL-520
Wire diameter:1.0-4.0
Final coil.O.D:Φ130-450mm
Min.final coil.I.D:Φ70
Max.finalcoil height:220

Device model: GWAT-80HM
Compatible magnetic ring (outer diameter): 31mm-55mm
Adapt to wire diameter: 1.0mm-2.5mm
Unilateral line length: 1200mm

Model:GW-C60
Voltage: 220V
Power: 10W
Size: 640*170*160mm
Maximum pin spacing: 60mm
Row spacing: 55mm

Model:GWM B790
Tape width:6-8-10-12mm （optional）
Max.final coil.O.D:50-180mm
Min.final coil.I.D:16mm

Equipment model: GWA-70HM
Adapt to the magnetic ring (outer diameter): 14mm-45mm
Adapt to wire diameter: 0.5mm-2.0mm
Length of unilateral line: 1200mm
