Insulation Paper Inserter Machine
Model:insulation paper inserter machine
Stator I.D.：30-120mm
Stator O.D. : 120-190mm
Stack height： 40-120mm
Number of slots：8-36slots
Description
|
Name |
Small type |
Middle type |
Big type |
|
Model Number |
GWK-269F |
GWK-270F |
GWK-271F |
|
Stator I.D.(mm) |
30-120 |
30-120 |
30-120 |
|
Stator O.D. (mm) |
Max 120 |
Max 160 |
Max 190 |
|
Stack height(mm) |
Max 40 |
Max 80 |
Max 120 |
|
Number of slots |
8-36 |
8-36 |
8-36 |
|
Power(KVA) |
0.75 |
0.75 |
1.5 |
|
Driving mode |
Servo motor |
Servo motor |
Servo motor |
|
Net weight (kg) |
350 |
450 |
550 |
|
Machine size(mm) |
900*600*950 |
900*600*1100 |
1100*700*1150 |
Function：
This machine is specially designed for slot ce paper insertion in medium and small size stators. A procedure is done by the machine automatically except to put on and take off the stator, The complete inserting time for 24 slots stator can be shorten to 10 sec/stator. The production cost will be highly reduced by decreasing the material loss and labor costs.
Features：
1. High insertion speed(about 0.4 sec/slot), labor saving, cost reduction, and stable quality output.
2. Easy adjustment while changing stack height of stator or width of insulating paper
3. Change the tooling design to meet the different shapes of stater slots.
